Drum Size(D×L)

250×200mm

Bunker Opening scale

0-20mm

Drum Speed

50-300r/min

Feed Chute inclination

2°-30°

Corona Electrode

(electrode wire diameter×qty)

0.2mm;1-5pcs

Process material size

0.04-1mm

Static Electrode(diameter×qty)

30mm,1pcs

Process Capacity

15-30Kg/h

Electrode

Control

Radial displacement

50mm

High voltage power supply

800W

Circumferential angle

60°

Maximum Voltage

60Kv

Bush(external diameter×core diameter)

105×60mm

Dimensions

920×1120×1850mm

Bush speed

100-600r/min

Weight

400Kg

Drum

heating

Temperature

50-60℃

Bunker

heating

Temperature

100-300℃

Power

900W

Power

900W
